Stainless Steel Flats
Your source for Stainless Steel Flats, Manufacturer and Supplier of the most qualitative range of Steel Flats
Look for Stainless Steel Flats at best price across industry.
Grand Metal Corporation is acknowledged as a manufacturer, exporter & suppliers of Steel Flats, available in a variety or grades, materials, and finishes, in metric and inch sizes. We have a full range available always, with unrivalled lead times, superior quality and exemplary customer service, leading Steel Flats. Our inventory in stainless steel round bar ranges from 1/8" to 24" in diameter. We are the industry leader in long length bar with inventory ranging from 20'-24' R/L. we're able to provide Stainless Steel material for projects requiring lengths longer than the industry standard 12' lengths. The long lengths also provide flexibility for part lengths that would typically leave excess scrap from the standard 12' lengths.
Grand Metal Corporation carries a variety of Stainless Steel Flats and supply at Best suitable price.
Useful Information of Steel Flats
Features
Chemical Composition
| Carbon % |
Manganese |
Sulphur |
Phosporous |
Silicon |
Corbon |
| Max % |
Max % |
Max % |
Max % |
Equivalent |
| 0.23 |
1.5 |
0.045 |
0.045 |
0.4 |
0.42 |
| tolerance |
0.05 |
0.005 |
0.005 |
0.03 |
|
| 0.02 |
| |
|
|
|
|
|
Mechanical Property
| Tensile Strength |
Yield Stress, Min, MPa |
% Elongation at gauge length 5.65 √Ѕo |
Bend Test |
| Min, Mpa |
| mm |
<20 |
20-40 mm |
>40 |
min |
min |
| mm |
mm |
| 410 |
250 |
240 |
230 |
23 |
3t* (*t is 3 times thickness) |
Stainless Steel Flats Available Size
| Size in mm |
Average Weight |
| KG/MTR |
KG/FT |
| 12 |
0.9 |
0.3 |
| 14 |
1.2 |
0.4 |
| 16 |
1.6 |
0.5 |
| 18 |
2 |
0.6 |
| 20 |
2.5 |
0.8 |
| 22 |
3 |
0.9 |
| 25 |
3.9 |
1.2 |
| 28 |
4.8 |
1.5 |
| 30 |
5.55 |
1.69 |
| 32 |
6.3 |
1.9 |
| 34 |
7.14 |
2.18 |
| 36 |
8 |
2.44 |
| 40 |
9.9 |
3 |
| 45 |
12.49 |
3.81 |
| 50 |
15.4 |
4.7 |
| 56 |
19.34 |
5.89 |
| 60 |
22.2 |
6.8 |
| 63 |
24.47 |
7.46 |
| 63.5 |
24.86 |
7.58 |
| 65 |
26.05 |
7.94 |
| 70 |
30.2 |
9.2 |
| 73 |
32.86 |
10 |
| 75 |
34.72 |
10.58 |
| 78 |
37.51 |
11.43 |
| 80 |
39.5 |
12 |
| 83 |
42.47 |
12.95 |
| 85 |
44.55 |
13.58 |
| 90 |
50 |
15.2 |
| 92 |
52.19 |
15.91 |
| 93 |
53.39 |
16.27 |
| 95 |
55.65 |
16.95 |
| 100 |
61.66 |
18.79 |
| 105 |
67.98 |
20.72 |
| 110 |
74.6 |
22.74 |
| 115 |
81.64 |
24.88 |
| 125 |
96.34 |
29.36 |
| Rolling Tolerances |
| Size |
Ovality |
Weight |
| up to 25 mm ± 0.5 mm 25 mm to 35 mm ± 0.6 mm 35 mm to 50 mm ± 0.8 mm 50 mm to 80 mm ± 1 mm 80 mm to 100 mm ± 1.3 mm 100 mm and above ± 1.6 % of diameter. |
± 75 % of total tolerance specified on the size. |
10 mm to 16 mm ± 5 % |
| 16 mm and above ± 3 % |
Contact Grand Metal Corporation today for a best offer & competitive quotation…
Call: +91 98927 02393, 97690 58811
