316L Stainless Steel Screw

316L Stainless Steel Screw
Manufacturer of high purity of grade astm a193 316L Stainless Steel Screw

Best source for astm a193 grade 316LStainless Steel Screw & astm a193 stainless steel heavy hex bolts with entire diameter, with numerous universal length and thread lengths

Grand Metal Corporation is acknowledged as manufacturer, exporter & supplier of astm a193 grade 316LStainless Steel Screw, available in a various range with multiple grade and materials, also with good finishes, multiple size. Well known fasteners distributor in fastener products for companies engaged in Equipment Manufacturing for Mining, Oil Refineries, Chemical manufacturing, Steel and Aluminium Manufacturing, and Industrial Construction.

Stainless steel fasteners are used extensively throughout industry for both original equipment manufacturer as well as for replacement. The stainless steel fastener materials are identified as the B8 class of alloys and are identified in the ASTM Specification A193/193M (Standard Specification for Alloy Steel and Stainless Steel Bolting Materials for High Temperature Service). The corresponding nut specification is ASTM Specification A194/194M.

We are having a variety of 316L Stainless Steel Screw from Carbon Steel, Stainless Steel and High Nickel Alloy -F467 NiCu 400 (Monel) and commercial 18-8/18-8, 18-8 Stainless Steel. We supply 316L Stainless Steel Screw at reasonable price.

Our Stainless Steel Fasteners product range includes 316L Stainless Steel Screw, Hexagon head bolt, Hexagon head screw, Round head square neck bolt, Hexagon socket head cap screw in full thread and half thread, Hexagon wood screw, Hexagon socket button head screw, Hexagon socket button flange screw, Hexagon socket counter sunk head cap screw in full thread and half thread, square nuts, square weld nuts, hexagon weld nuts, thick nyloc nuts, hexagon flange nuts, threaded rods, dowel screws and many more. We provide products as per DIN, ANSI, JIS standards.

316L Stainless Steel Screw

Product & Material 316L  Stainless Steel Screw Size Length Standard & Specification
316L  Stainless Steel Screw M02 to M33 3 mm to 200 mm DIN
ISO
JIS
GB
IS
BS
ASTM
Packing: IN BULK : Canton/pallet, Small Boxs/carton/ pallet, or customer request
Origin and service-region: European
Origin of 316L Stainless Steel Screw Are Western European. However projects with eastern origin are possible on request.
TEST CERTIFICATE Manufacturer Test Certificate as per EN 10204 / 3.1
Product Grades: 316L, 316LL, 316H, 316HL, 316HTi, 200 series

Property Class

For Bolts & Screws A2-70, A2-80, A4-70, A4-80, F593C, F593D, F593G, F593H
For Nuts A2-70, A2-80, A4-70, A4-80, F594C, F594D, F594G, F594H, A2-035, A4-040
For SHCS F837B, F837C, F837E, F837
For Threaded Rods A2-70, A2-80, A4-70, A4-80, F593C, F593D, F593G, F593H, B8, B8M CL1 & CL2
Our Stainless Steel Fastener plant is equipped with various testing facilities like Tensile Testing Machine also known as tension testing. We also conduct other tests like Hardness Test, IGC Test, Positive Material Identification Test to ensure that all the product going out of our manufacturing plant are the best in terms of quality.

Fasteners ASTM Grades
ASTM A193 Grade B5, ASTM A193 Grade B6, ASTM A193 Grade B7, ASTM A193 Grade B16, ASTM A193 Grade B8, ASTM A193 Grade B8C, ASTM A193 Grade B8M, ASTM A193 Grade B8T, ASTM A193 Grade B8, ASTM A193 Grade B8C, ASTM A193 Grade B8M, ASTM A193 Grade B8T, ASTM A320 Grade L7, ASTM A320 Grade L7A, ASTM A320 Grade L7B, ASTM A320 Grade LC7, ASTM A320 Grade L43, ASTM A320 Grade B8, ASTM A320 Grade B8C, ASTM A320 Grade B8T, ASTM A320 Grade B8F, ASTM A320 Grade B8M, ASTM A320 Grade B8, ASTM A320 Grade B8C, ASTM A320 Grade B8F, ASTM A320 Grade B8M, ASTM A320 Grade B8T, SAE J429 Grade 5, ASTM A449, SAE J429 Grade 5.1, SAE J429 Grade 5.2, ASTM A325 Type 1, ASTM A325 Type 2, ASTM A325 Type 3, ASTM A354 Grade BB, ASTM A354 Grade BC, SAE J429 Grade 7, SAE J429 Grade 8, ASTM A354 Grade BD, SAE J429 Grade 8.1, ASTM A490

316L stainless Steel Screw Useful Data

SS 316L is a second one maximum useful grade (after 304); for surgical and food industry etc. Alloy addition of molybdenum prevents precise varieties of corrosion. It's also called marine grade chrome steel because of its accelerated resistance to chloride corrosion compared to type 304. 316Lis often used for constructing nuclear reprocessing flowers.

316Lfor severe environments. There are numerous commercial processes that require a better stage of resistance to corrosion than type 304 can provide. For these applications, kind 316Lis the answer. Type 316Lis likewise austenitic, non-magnetic, and thermally non hard enable chrome steel like type 304. The carbon content is held to zero.08% most, while the nickel content material is increased slightly. What distinguishes type 316Lfrom kind 304 is the addition of molybdenum up to a most of three%.

Molybdenum will increase the corrosion resistance of this chromium-nickel alloy to resist attack by way of many business chemical compounds and solvents, and, especially, inhibits pitting because of chlorides. As such, molybdenum is one of the single maximum useful alloying additives inside the fight against corrosion.

Ss 316Lis the principle stainless used within the marine surroundings, with the exception of fasteners and other objects where power and put on resistance are wanted, then kind 304 (18-eight) is generally used.

Analysis of Stainless Steel 316L

Carbon 0.08% max. Silicon 1.00% max.
Manganese 2.00% max. Chromium 16.00-18.00%
Phosphorus 0.045% max. Nickel 10.00-14.00%
Sulfur 0.030% max. Molybdenum 2.00-3.00%

Physical Property

Density  0.799g/cm3
Electrical resistivity 74 microhm-cm (20C)
Specific Heat  0.50 kJ/kg-K (0-100°C)
Thermal conductivity 16.2 W/m-k (100°C)
Modulus of Elasticity (MPa)  193 x 103 in tension
Melting Range 2500-2550°F (1371-1399°C)

Composition of both SS 316L and 316H

Lement Type 316L (%) Type 316HL (%)
Carbon 0.08 max. 0.03 max.
Manganese 2.00 max. 2.00 max.
Phosphorus 0.045 max. 0.045 max.
Sulfur 0.03 max. 0.03 max.
Silicon 0.75 max. 0.75 max.
Chromium 16.00-18.00 16.00-18.00
Nickel 10.00-14.00 10.00-14.00
Molybdenum 2.00-3.00 2.00-3.00
Nitrogen 0.10 max. 0.10 max.
Iron Balance Balance
